Open image in slideshow, H4 Electric Chain Hoist, 500 lb. Load Capacity, 460V, 15 ft. Hoist Lift, 15/2.5 fpm

H4 Electric Chain Hoist, 500 lb. Load Capacity, 460V, 15 ft. Hoist Lift, 15/2.5 fpm

$20,450.35

Specification:

  • Electric Hoist Item: Chain Hoist
  • Load Capacity: 500 lb.
  • Hoist Lift: 15 ft.
  • Classification: H4
  • Number of Speeds: 2
  • Lift Speed: 15/2.5 fpm
  • Motor HP: 0.75
  • Voltage: 460
  • Phase: 3
  • Min. Between Hooks: 16-5/16"
  • Amps @ Low Volts: 3.4
  • Housing Depth: 16-5/16"
  • Housing Length: 13-13/16"
  • Housing Width: 8-1/2"
  • Reeving: 1
  • Brake: DC Current
  • Clutch: Friction
  • Control: 110V Push Button Control Pendant
  • Control Cord: 11 ft.
  • Color: White
  • Finish: Epoxy Paint
  • Hz: 60
  • Lubrication: Food Grade Oil
  • Thermal Protection: Yes
  • Wheel Material: Stainless Steel
  • Trolley Wheel Dia.: 2-13/16"
  • Standards: ASME B30.16, ASME HST-1M, FDA, RoHS
  • Includes: Geared Trolley, Chain Container, Quick Disconnect Plugs On Pendant and Power Cord
  • Hoist Mount: Geared Trolley
  • Manufacturers Warranty Length: 3 yr., 10 yr. Brake Warranty"
